BLDC Speed Controller

$ 439.00 NZD

Speed controller which can be used with a Smart Drive PMA.

We offer motor applications for 48-84V input for the same BLDC controller.

Low voltage protection is set to 30V.  Unit will re-start from about 38V.

The maximum speed of this controller is just over 1000rpm @ 60V

Each controller is tested prior to despatch and all wires are clearly labelled.

We supply it with a pot so you can accelerate the motor as required.

It also has an ignition wire for key start/stop if required.

To get reverse just switch any 2 of the 3 Smart Drive PMA connection wires.

The maximum speed that can be obtained from a Smart Drive PMA depends on the V/rpm of the stator fitted.

For motor and BLDC options click here.

For more detailed information on selecting the correct stator required read this document.

 Refer to PowerSpout Document Index Links for a complete index of documents.
