Complete 36 Pole PMA

$ 599.00 NZD

Complete 36 Pole PMA

$ 599.00 NZD

Weight: 8.6 kg

Doing a DIY project? Rather than locate all the parts you need, buy a complete PMA ready to go.

Select the V/rpm of the stator you require for your application from the drop down list. This 36 pole PMA with a type 4 rotor is suitable for up to 1.6 kW at 1600 rpm. All 36 pole stators are of the cog-free design which makes them suitable for wind turbine applications.

Each PMA comes with the following parts:

  • Stator
  • Type 4 magnetic rotor – 1.0 W/rpm maximum output (High Power)
  • Type 1 shaft and retaining nut
  • Bearing block, bearings and fixings
  • Seal kit

    For selection of correct V/rpm  PMA  applications read this document

    For selection of correct V/rpm  BLDC applcations read this document

    Please note this product is not suitable as a replacement part for PowerSpout turbines.

    Refer to PowerSpout Document Index Links for a complete index of documents.
